Dreamvision Focus
Since 1996, DreamVision, in the shadow of the world-famous Montmartre hill in Paris, has been developing and refining the latest advancements in digital display technology in order to provide state-of-the-art video products for Home Cinema.
Specifications
Model
Focus
Part number
R9202210
Emission method
Single Chip DLP 4K panel
Panel Resolution
3 840 x 2 160 pixels
Dynamic contrast ratio
5,000,000:1 ANSI
Projection lens
Throw ratio 1.52:1 – 2.45:1
Zoom 1.6x motorized
± 100% vertical shift, motorized
± 40% horizontal shift, motorized
Keystone correction
± 35% vertical, ± 35% horizontal and corner keystone
Light Source
Laser ALPD with High uniformity 90%
Brightness
6,000 ANSI Lumens
Lifetime
Up to 25,000 hours in normal mode
Screen size
50” to 300”
Multimedia
- Operating System : Android 7.1
- Memory : 2 Gb RAM + 16 Gb ROM
Inputs:
- HDMI : 2x HDMI 2.0 with HDCP – Ultra HD BluRay compatible with 4K and HDR
-
USB : 1x USB type A
: 1x USB type B - 3D Sync : 1x 3D Sync In
-
Wireless : 1x Bluetooth 4.2
: 1x Wi-Fi 802.11 a/b/g/n/ac
Outputs:
- Built-in loudspeakers : 1x 10W
- Audio outputs : 1x S/PDIF fiber optic digital audio
- 3D Sync : 1x 3D Sync Out and IR 3D Out
Color
REC.709 gamut
Video Processing
Video formats: MPEG-1/2/3 up to 1080p30, H265 4Kp60, HDR10 and 3D
videos (DLP-LINK glasses required)
Dolby Atmos and DTS:X supported
Audio formats: MPEG 1/2/3
Photo formats: JPG, BMP, PNG, GIF
Light source lamp
Laser ALPD source – 25,000 hours in normal mode
Noise level
36 dB
Power Requirements
110V – 240V AC 50Hz/60Hz
Power Consumption
450W
0.5W in Standby Mode
< 5W in Standby Mode with LAN
Unit size (W x H x D)
44 x 34 x 10 cm (17.3” x 13.4” x 3.9”)
Net Weight
10.1 kg (22.3 lbs)
Operation Environment
Temperature: 0°C to 40°C (Storage Temperature: -10°C to 60°C)
Humidity: 10% to 85% without condensation
